ASR-C485-24DC - RS485 Communication Module Smart Relay

Part Number ASR-C485-24DC

Standard Features

Supports upto 48 I/Os (32 digital inputs & 16 digital outputs)
DST Feature Available
Backlit LCD Screen for display & modification of pre-selected parameters of functional blocks, viewing I/O status and programming on the device
PC software for programming, online & offline simulation, documentation & printing
Designed for use in automation for commercial & Industrial sectors
Modbus Communication

Downloads:

Smart Relays - Module Type: RS485 Communication Module
Smart Relays - Supply Voltage: 12-24 VDC
Smart Relays - Weight: 0.19 lb. (84 g)
Smart Relays - Operating temperature: -10°C to +55°C
Smart Relays - Storage temperature: -20°C to +70°C
Smart Relays - Input: TTL Level
Smart Relays - Output: RS-485 protocol (two wires, D+, D-)
Smart Relays - Number of Nodes: 32 standard unit loads
Smart Relays - Isolation Voltage: 2000 Vrms
Smart Relays - Baud Rate: 300, 600, 1200, 2400, 4800, 9600
Smart Relays - LED Indicators: Red LED’s for Tx & Rx. Green LED for Power indication
